Hofmann Power Star 25kW – 30kW – Commercial device, big savings
Using the latest inverter+EVI technology, the powerSTAR series is designed as a highly energy efficient and stable heating solution, with a wide heating capacity from 30kV to 180kV.
Not only with the inverter compressor, powerSTAR can automatically adjust the temperature higher than the heating demand, to optimize the efficiency of the whole system, with EVI technology, it can always ensure a stable heating effect, to reduce energy consumption on cold days.
powerSTAR is a simple yet powerful solution that meets the heating, cooling and stable hot water needs of commercial applications such as apartments, hotels, schools, etc.
Specifications
| Hofmann Power Star 25kW – 30kW | ||||||
|---|---|---|---|---|---|---|
| Name | powerSTAR25M | powerSTAR30M | ||||
| Model | JM | PAEVH-25V4DEA | PAEVH-30V4DEA | |||
| IP rating | IPXX | IPX4 | IPX4 | |||
| Power supply | ||||||
| Power supply – outdoor unit | Outdoor unit | V/Hz/Ph | 400V/50Hz/3Ph | |||
| Unit fuse | AND | 3P/25A/C | ||||
| Performance | ||||||
| SCOP – Average climate, low temperature | W | 4.04 | 4.06 | |||
| Energy class | A++ | |||||
| Min/max heating capacity (1) – A7/W35 | kW | 7.9 ~ 25.1 | 15.2 ~ 28.7 | |||
| Electric heating input power min/max(1) | kW | 2564 ~ 6172 | 3467 ~ 7488 | |||
| COP min/max (1) | W / W | 3.07 ~ 4.41 | 3.83 ~ 4.43 | |||
| Min/max heating capacity (2) | kW | 9.9 ~ 24.8 | 12.2 ~ 29.4 | |||
| Electric heating input power min/max(2) | kW | 3141 ~ 7625 | 3769 ~ 9035 | |||
| COP min/max (2) | W / W | 3.16 ~ 3.43 | 3.26 ~ 3.43 | |||
| Min/max heating capacity (3) | kW | 10.6 ~ 21.5 | 15.2 ~ 26.8 | |||
| Electric input cooling power min/max (3) | kW | 2528 ~ 7678 | 3253 ~ 8765 | |||
| EER min/max (3) | W / W | 2.81 ~ 4.20 | 3.06 ~ 4.68 | |||
| Minimum/maximum cooling capacity (4) | kW | 7.1 ~ 18.1 | 7.3 ~ 21.2 | |||
| Electric input cooling power min/max (4) | kW | 2570 ~ 6746 | 3121 ~ 7960 | |||
| EER min/max (4) | W / W | 2.46 ~ 3.04 | 2.33 ~ 2.84 | |||
| Min/max operating temp. in mode | Heating | °C | -30 ~ 55 | |||
| Cooling | °C | 15 ~ 55 | ||||
| Max. temp. in heating mode | °C | 60 | ||||
| Max. temp. in heating mode | °C | 20 | ||||
| Min. temp. in cooling mode | °C | 7 | ||||
| Audio power level | Outdoor unit | dB(A) | 62 | |||
| Indoor unit | dB(A) | / | ||||
| Components | ||||||
| Compressor heater | W | 30 | 30 | |||
| Fan | Set | Com. | 2 | |||
| Air flow | m³/h | 5250*2 | 5250*2 | |||
| Rated power | W | 93*2 | 93*2 | |||
| Blade diameter | mmm | Φ552*2 | Φ552*2 | |||
| Hotplate | Water pressure. cap | kPa | 22 | |||
| Refrigerant | Type | / | R410A | |||
| Fill in | Kg | 4.4 | 5.2 | |||
| Compressor | Type | / | Inverter+EVI | |||
| Compressor oil | Type | / | FVC68S | |||
| Complete oil volume | L | 1.9 | 1.9 | |||
| Compressor heater | W | 30 | ||||
| Compressor brand and type | / | Panasonic, double rotation | ||||
| Hydraulics | ||||||
| Minimum water flow | m³/h | 2.8 | 2.8 | |||
| Normal water flow | m³/h | 4.3 | 5.2 | |||
| Hydraulic connections | Inch | 1 12″ Inner Gorge | ||||
| Dimensions and weight | ||||||
| Net dimensions (L x W x H) | Outdoor unit | mmm | 1215 x 460 x 1445 | 1295 x 455 x 1450 | ||
| Indoor unit | mmm | 385 x 476 x 150 | ||||
| Gross dimensions (L x W x H) | Outdoor unit | mmm | 1265x480x1580 | 1325 x 475 x 1580 | ||
| Indoor unit | mmm | 400x490x180 | ||||
| Net weight | Outdoor unit | kg | 165 | 180 | ||
| Indoor unit | kg | 9 | ||||
| Gross weight | Outdoor unit | kg | 185 | 200 | ||
| Indoor unit | kg | 10 | ||||
| Comes with the unit | ||||||
| Wi-Fi | Yes / No | That | ||||
| Communication cable | m | 20 | ||||
| Temperature sensor | m | 5K,B=3470, 5K,B=3950 | ||||
Note:
(1) Heating conditions: water inlet/outlet temperature: 30°C/35°C, ambient temperature: DB 7°C/VB 6°C;
(2) Heating conditions: water inlet/outlet temperature: 40°C/45°C, ambient temperature: DB 7°C/VB 6°C;
(3) Cooling conditions: water inlet/outlet temperature: 23°C/18°C, ambient temperature: DB 35°C/VB 24°C;
(4) Cooling conditions: water inlet/outlet temperature: 12°C/7°C, ambient temperature: DB 35°C/VB 24°C.
(5) Specifications are subject to change without notice. For actual unit specifications, please refer to the unit designations.
